6 Antennas 360 Degree Shielding Wireless Cellular High Power Portable Manpack Jammer EST-BP30

SKU: #001 - In Stock
USD$1,199.00

  • airport Shipping:  International shipping available
  • delivery_food Shipping time:   Standar(10-20 business days), Rush(5-10 business days)
  • chip Discount:  Get 2% discount on orders of USD $100.00,Get 3% discount on orders of USD $200.00
  • compass Handling time:  Ships within 3 business days after receiving cleared payment
  • available_updates Returns:  7 days money back guaratee,buyer pays return shipping

Product Detail

Customer Reviews

Shipping Guide

Delivery Time

Product Tags

1. Introduction

This high power portable manpack jammer EST-BP30, implementing the most effective and reliable RF jamming technology and equipped with a fully-integrated broadband jamming system. This backpack jammer is highly portable and light weight. It plays an important role to use the heavily loaded vehicle and trolley-type devices in some extreme hard situation. The operator can carry it forward through the hills and muddy road, as well as climbing steep mounts and stairs avoid casualties and improve the combat efficiency. It can jam 5-80 meters radius range, to make the mobile phone or other kinds of devices can't work and get the wireless signal, but it does not interfere with other electronic equipment. Its overall RF output power is more than 55W, developed specially for personnel and other sensitive facilities, such as military installations, and government compounds.

2. Technology

* available TX frequency, or can be customized

CH1: GSM: 800-900MHz (40dBm / 10W)

CH2: PCS/PHS: 1900-2000MHz (40dBm / 10W)

CH3: GSM / 4G LTE: 1700-1800MHz (37dBm / 5W)

CH4: 3G UMTS: 2100-2200MHz (40dBm / 10W)

CH5: 4G: 700-800MHz (37dBm / 5W)

CH6: 4G WiMAX: 2496-2690MHz (37dBm / 5W)

CH7: VHF: 135-175MHz (37dBm / 5W)

CH8: UHF: 400-470MHz (37dBm / 5W)

*Colour: Black

*Antenna: 8 external high gain omni-directional antennas

*Jamming Radius: Radius 5-80 M the signals must ≤-85dBm in the location

The jamming radius still depends on the strength signal in given area

*Safety Regulation: AC Adapter UL (E190582) / CSA (LR112971 Level 3)

*Jamming Type: sweep jamming

*Single Output Power: +37-40dBm / +5-10W

*Total Output Power: 55W

*Working Power Input: AC 110V 60Hz ~ AC 240V 50Hz, available for DC 24V 20AH built-in Li-ion battery (support 1.5-2.5 hours continuously working), and DC 12V car charger plug in

*Control: wireless remote control (turn on and turn off)

*Dimension: 550(L)×150(W)×350(H)mm (not including antennas)

*Antennas Dimension: omni antenna Dia 20mm x Height 60mm (3-5dBi) x 8pcs

*Full Set Weight: 16.48kg

*Antenna Gain: 3dBi

*Working Temperature: -30℃ to +60℃

*Relative humidity: ≤85%(RH) (please keep the machine dry)

*Air pressure: 86~106kPa

*Available system: Include analog (AMPS,TACS,NMT) and digital (GPRS,GSM,3G,DCS,CDMA, PDC,TDMA,PHS,PCS,IDEN,W-CDMA,UMTS, Wi-Fi / Blue Tooth/wireless video,4G)

3. Features

*manual switch, with simple ON/OFF wireless remote control, easy to switch on/off of the jammer.

*backpack designed for portability and easy moving.

*ultra-wide band jamming coverage, effectively shielding 2G/3G/4G and VHF, UHF.

*efficient frequency division ensures the best interference effect on signals of different frequencies.

*efficient power distribution minimizes power loss and improves efficiency.

*support 3 kinds of power supply in AC110-220V / built-in high capacity Li-ion battery / DC 12V car charger.

*built-in efficient cooling fan and cooling fin ensures the product work stably in a long service life.

*the mobile phone signal jammer is made up of up-to-date paste components and integrated circuits. with advanced performance, it is easy to install and use, and can work continuously for a long time.

4. Operation Instructions

*open the package, take out the jammer and its accessories carefully to avoid any damage.

*screw the antennas to the correct position on the jammer as the number indicated.

*hang the jammer onto the wall with hanging height for 1.5-2 meters, choose a best place where its 5 fans (2 fans in right side, 2 fans in left side, 1 big fan in back side) with good cooling condition, do not shield and affect the fan space.

*it has totally 3 different kinds of working ways:

if you want to work with 110V AC power, insert the AC plug into the socket, connect to jammer, and then turn on the Toggle Switch at position #2, when the power indicator is lit, it means that the jammer starts working.

if you want to work with battery, turn on the Toggle Switch at position #3, when the power indicator is lit, it means that the jammer starts working.

if you want to work with 12V DC power, insert the car charger into the socket, connect to jammer, and then turn on the Toggle Switch at position #4, when the power indicator is lit, it means that the jammer starts working.

if you want to turn off the jammer, switch the Toggle Switch to the position #1, the power indicator unlit, it means the jammer is off, not working.

*the wireless remote control can only work for turn and turn off the jammer with 5-20meters distance, A for turn on, B for turn off.

*the installation location in the space of different sizes can be decided according to the following fig. Ex1: indoor small space (less than 200 square meter)

EX2: indoor big space (more than 200 square meter, preferably by the cellular mode) EX3: outdoor big space (more than 1000 square meter, preferably by the cellular mode)

*since the valid scope covered by the jammer is a round area with the isolator as the center, put the jammer in the center place where it installed to get the best performance.

*please keep away strong electromagnetic sources with heat sources to ensure high isolation affect and stable operation for a long time.

*switch off the device in time when not using it, lest the normal operation of mobile phones be affected.

*while using the isolator outdoors, be sure to keep it away from water or damp.

*keep away from caustic gases and liquids, and be sure to make it dust-proof and moisture-proof, lest the aging of the components inside should be accelerated.

5. Application Area

The mobile phone signal jammer will make effect only on the communication of mobile phones, instead of on other electronic devices and human bodies, thus can be used widely.

*conference room, auditoriums, law court, library, exam room, school, cinema, theater, and hopital etc.

*Oil station, gas filled station, oil field, oil depot etc.

*at places where using mobile phones is prohibited such as government, military, finance, security, police and command center etc.

6. Packing List

1pc x jammer main unit

1set x antennas (8pcs omni antennas)

1pc x AC power cable

1pc x battery charger

1pc x car charger

1pc x wireless remote control

1pc x backpack bag

1pc x user manual (optional)
